Pod light featuring advanced TIR optics for high efficiency and focus.

Description

<p><strong>Features</strong></p><ul><li>Advanced TIR optics provide high efficiency and focus</li><li>SAE-compliant road-legal output</li><li>Includes round bezel for factory-style appearance</li><li>Plug and play no modification needed</li><li>Durable powdercoated aluminum extrusion</li><li>Engineered and Assembled in USA</li></ul><br><p><strong>Overview</strong></p><p><strong>Overview. </strong>Upgrade your fog lights with our SS3 Type MR Fog Light Bracket Kit! Featuring higher output intensity than any other 3in light on the market these LED pods have been designed for maximum functionality with custom-engineered TIR optics shining in highly useful beam patterns all in a durable package. With the included round bezel the SS3 Fog Kit has a clean factory-style appearance only much brighter!</p><p><strong>Plug and Play. </strong>Thanks to custom-molded brackets the SS3 Fog Light Bracket Kit can be installed on your vehicle in minutes. Simply remove your factory fog light assembly and ours will bolt right in its place! Wire adapters are included with the kit allowing you to connect the lights to your factory bulb sockets – no additional wiring needed!</p><p><strong>Backlight Functionality.</strong> The Stage Series 3in LED Pod is now available with a distinctive backlight in a brilliant amber color. The SS3's backlight fully illuminates the TIR optic providing a more unique and modern look than the small indicator LEDs found in other products.</p><p><strong>SAE Compliant.</strong> When installed as a pair and aimed in accordance with your state's regulations the Driving White pattern meets SAE J581 standard as a Driving/Auxiliary High Beam Light and the Fog pattern meets SAE J583 standard as a Foglamp for legal on-road use.</p>

Additional Attributes:

GTIN: 00691025934045
Voltage: 9-30V
DOT Approved: Yes
Street Legal: Yes
Fog Light Lens Color: Clear
Bracket Color: Black
Lens Material: Polycarbonate
Terminal Type: Pin
Mounting Hardware Included: Yes
Grade Type: Performance
Housing Material: Aluminum
Light Shape: Rectangular
Light Housing Color: Black
812: No
Wattage: 36
Add-On: N/A
Color Temp: 6000K
Compliance Rating: SAE J583 Foglamp Beam Pattern
Input Power (watts): 36
Intensity (lux): 11,900 cd
Measured Output (lumens): 3,000 lm
Operating Temperature: -40C to 85C (-40F to 185F)
Operating Voltage: 9-30V
Prop 65 Yes/No: N

Extended Information:

Emissions : Emissions Compliance Exempt
Life Cycle Status: Available To Order

Packaging:

Quantity of Each: 1
Package UOM: EA
Dimension: 14 x 11 x 4 inches
Weight: 4 PG

PDF:

SS3_Type_MR_Bracket_Mounting_Guide
